Char-Broil Performance T-47D User Manual

PARTS LIST
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
12
Key Qty Description
A 1 BOTTOM SHELF
B 1 TANK SCREW, F/ BOTTOM SHELF
C 2 CASTER, LOCKING
D 2 CASTER, FIXED
E 1 CART LEFT SIDE PANEL
F 1 GROMMET, F/ REGULATOR HOLE
G 1 CART RIGHT SIDE PANEL
H 1 CART LOWER BACK PANEL
I 1 FRONT BRACE
J 1 HEAT SHIELD, F/ TANK
K 1 LEFT RAIL, F/ GREASE TRAY
L 1 RIGHT RAIL, F/ GREASE TRAY
M 1 FIREBOX
N 1 MATCH HOLDER
O 4 MAIN BURNER
P 2
ELECTRODE, F/ MAIN BURNER,
900MM WIRE
Q 2
ELECTRODE, F/ MAIN BURNER,
600MM WIRE
R 3 CARRYOVER TUBE W/ COTTER PIN
S 1 IGNITER SWITCH MODULE
T 1 HOSE VALVE REGULATOR ASSY
U 1 MAIN CONTROL PANEL
V 1 ELECTRONIC IGNITION MODULE
W 1 BUTTON, F/ EI MODULE
X 1 ELECTRODE WIRE, F/ SIDEBURNER
Y 5 BEZEL, F/ CONTROL KNOB
Z 5 CONTROL KNOB
AA 4
TEMPERATURE GAUGE, UFC
MOUNTED
BB 1 CART UPPER BACK PANEL
CC 1 LEFT SIDE SHELF F/ S/B
DD 1 FASCIA, F/LEFT SIDE SHELF
EE 1 DRIP PAN, F/ SB
FF 4 RUBBER BUMPER, F/ LID
GG 1 LID, F/ SB
HH 1 SIDEBURNER
II 1 ELECTRODE, F/ SB
JJ 1 RIGHT SIDE SHELF
KK 1 FASCIA, F/ RIGHT SIDE SHELF
LL 1 TOP LID
MM 1 HANDLE F/ TOP LID
NN 2 RECTANGULAR BUMPER, F/ TOP LID
Key Qty Description
OO 1 LOGO PLATE
PP 1 HARDWARE F/ TOP LID
QQ 1 LEFT DOOR, NO HANDLE
RR 2 DOOR HANDLE
SS 1 RIGHT DOOR, NO HANDLE
TT 4 FLAME TAMER
UU 4 COOKING GRATE
VV 1 GRATE, F/ SB
WW 1 WARMING RACK
XX 1 GREASE TRAY
YY 1 TANK EXCLUSION, WIRE FRAME
ZZ 1 TANK RESTRICTION BAR
AAA 1 BEZEL, F/ AUTO CLEAN
BBB 1 KNOB, F/ AUTO CLEAN
Key Qty Description
… 2 DOOR MAGNET
… 1 CASTER PIN
… 1 HARDWARE PACK
… 1 ASSEMBLY MANUAL, ENGLISH
… 1 IR CLEANING TOOL
NOT Pictured

Char-Broil Performance T-47D Specifications

General

Brand	Char-Broil
Model	Performance T-47D
Category	Grill
Language	English
