HOW TO ASSEMBLE
Assembly:
1. Before each use wash all parts with warm soapy water before assembly.
2. Ensure grinder is unplugged before performing any assembly.
3. Loosen the LOCKING KNOB and install the AUGER HEAD into grinder body until
completely engaged with drive mechanism.
4. While holding grinder head with one hand, turn AUGER HEAD LOCKING KNOB
clockwise until tight. There is a small recess in the AUGER HEAD that will align
with the screw.
5. Insert the AUGER into the AUGER HEAD and align the spindle with internal gear
drive.
6. Install the CUTTING BLADE with at surface facing away from grinder body onto
the square drive of the AUGER.
7. Position the CUTTING PLATE onto the spindle at the end of the AUGER so that
the plate sits ush against the at portion of the CUTTING BLADE. Ensure that
the notch on the CUTTING PLATE lines up with the notch on the AUGER HEAD.
The plate should sit approximately ush with the end of the AUGER HEAD.
8. Install the grinder HEAD COLLAR over the CUTTING PLATE by turning
clockwise on the threads of AUGER HEAD.
NOTE: DO NOT over tighten the grinder HEAD COLLAR.
9. Place the HOPPER on top of the AUGER HEAD.
10. Use the FOOD PUSHER to gently feed food, one piece at a time. DO NOT force
the food into the AUGER HEAD. Meat pieces should be no larger than 1" x 1".
