26
Step 10
Attach right side door bracket to
right front cart panel using two
M4 X 10mm bolts (silver). The right
side door bracket is stamped with
the letter "R".
Step 11
Attach left side door bracket to left
front cart panel using two
M4 X 10mm bolts (silver). The right
side door bracket is stamped with
the letter "L".
Step 12
Insert pin in bottom of right side
door into hole in bottom front cart
leg then align door with right side
door bracket. Depress spring pin
located on top edge of door and
slide door toward right side door
bracket until spring pin locks into
hole in door bracket. Repeat for
other door.
Step 13
Attach side table front panel to side
table with three M6 X 12mm bolts
(silver) and star washers (silver).
Step 14
Attach side burner front panel to
side burner with three M6 X 12mm
bolts (silver) and star washers
(silver).
Spring Pin
To Next Page
