Step 20
Attach side burner igniter lead wire
to the electrode as illustrated.
Step 21
Place the side burner grate onto
the side burner table.
Step 22
Insert grease tray into opening on
backside of grill. Make sure to slide
tray onto tracks as illustrated.
Step 23
Slide grease cup into grease cup
bracket located under grill bottom
on backside of grill.
29
Grease Tray
Side Burner
Igniter Lead
Electrode
Grease Cup
