Chase Research IOLAN+ - Server Statistics Pop-Up Menu

125
Troubleshooting & Maintenance
** Administrator ** SERVER STATISTICS REMOTE-ADMIN
=== ETHERNET ===
Tx: Pkts: 395 Errors: 0 Collisions: ===== Statistics =====
Retries : 0 Resets: 0 Busy: | ETH/TTY/GATEWAY |
Rx: Pkts: 866 Bufs: 170/300 No Bufs: | IP/ICMP/UDP |
Prot: 101 Miss: 0 Busy: | TCP |
| Users |
=== SERIAL LINES === | Framed Link Status |
Tx: chars: 6,561 psec: 2 | Netstat |
Rx: chars: 2,752 psec: 1 | Gateway |
Malformed: 0 Lost: 0 OverRuns: | Slip |
Buffer failures: 0 | Clear counters |
| Restore counters |
=== ROUTING STATISTICS === | Port Status |
bad redirects: 0 dynamic: 0 ne | Line Status |
unreachable: 0 wild card: 0 | LPD Status |
| PPP Status |
Uptime: 0 days 00:41:49 hours Memory free:182768 ======================
________________________________________________________________________________
Figure 49: Server Statistics pop-up Menu.
All of the IOLAN+ statistics screens are now accessible
through this
Statistics pop-up menu. Pressing in any of
the IOLAN+ statistics screens displays the same pop-up menu.
A summary of each is provided and then the most important
screens are briefly described:
ETH/TTY/
GATEWAY
This is a general overview of Ethernet activity, serial activity
and gateway stats. It shows characters passed and uptime.
IP/ICMP/UDP
This is a comprehensive screen of networking protocol stats
for IP, ICMP and UDP. You can identify bad IP packets
coming in from your network.
TCP This is a comprehensive screen of TCP protocol stats. You
can identify bad TCP packets coming in from your network.
