Hunt groups: Hunt groups are supported on IOLAN+ for
printing. To use this, use the same number in
the
Port Setup local port field ( i.e. 1006).
7.2Using LPD
IOLAN+ can be setup for receiving print jobs via LPD and
this is a very simple method. It works for both Windows
®
and Unix systems.
Configuration
** Administrator ** PORT SETUP MENU REMOTE-ADMIN
Hardware Flow ctrl Keys
Speed [9600 ] Flow ctrl [Hardware] Hot [^]] Intr [^C]
Parity [None] Input Flow [Enabled ] Quit [^@] Kill [^U]
Bit [8] Output Flow [Enabled ] Del [^@] Sess [^@]
Stop [1 ] Echo [^@]
Break [Disabled] IP Addresses
Monitor DSR [No ] Src [ ] Mask [ ]
Monitor DCD [No ] Dst [ ]
User Options Access
Name [LPD_printer ] Keepalive [No ] Access [Remote ]
Terminal type [ ] Rlogin/Telnet [Telnet] Authentication [None ]
TERM [ ] Debug options [No ] Mode [Raw ]
Video pages [0] Map CR to CR LF [No ] Connection [None ]
CLI/Menu [Menu] Hex data [No ] Host [ ]
Reset Term [No ] Secure [No ] Remote Port [0 ]
MOTD [No ] Local Port [515 ]
Figure 25: LPD printing - Port Setup Menu screen.
The following fields are important:
Flow control: Set your IOLAN+ port flow control to Hardware .
Then set your printer to use ‘DTR Pacing’ or
‘Hardware’ or ‘Ready/Busy’ flow control. Use
the RS-232 cable pinout described below, as this
will save a print job if the printer is turned off or
the cable becomes detached. In your cable, wire
the printer’s pin 20 (DTR) to the IOLAN+ pin 5
(or CTS). Also, cross pins 2 and 3.
