To Next PageTo Next PageWhat to do if my Chauvet Constellation DMX-800 Light Fixture has no power?
If your Chauvet Light Fixture isn't powering on, first, ensure that the power is reaching the mains. Then, check the device's fuse, both internal and external.
Why does the breaker/fuse keep blowing on my Chauvet Light Fixture?
If the breaker or fuse keeps blowing on your Chauvet Light Fixture, check the total load placed on the device.
How to fix a Chauvet Light Fixture that is not responding?
If your Chauvet Light Fixture isn't responding, check the DMX Dip switch settings for correct addressing, inspect the DMX cables, and verify the polarity switch settings.
What to do if I have a loss of signal with my Chauvet Constellation DMX-800?
If you're experiencing signal loss with your Chauvet Light Fixture: * Use only DMX cables. * Install a terminator. Also, keep DMX cables separated from power cables or black lights.
Why is the beam very dim on my Chauvet Light Fixture?
If the beam on your Chauvet Light Fixture is very dim or not bright, try cleaning the optical system or replacing the lamp. Also, check the 220/110v switch for the proper setting.
What to do if Chauvet Light Fixture is on but there is no movement to the audio?
If your Chauvet Light Fixture is on but not responding to the audio, ensure you have the correct audio mode selected on the control switches. If the audio is provided via a ¼” jack, verify that a live audio signal exists and adjust the sound sensitivity knob.
Why do the lamps cut off sporadically on my Chauvet Light Fixture?
The lamp may be at the end of its life, or the fixture is overheating. It could also be a bad lamp.
What to do if Chauvet Constellation DMX-800 will not come on after power failure?
Some discharge lamps require a cooling-off period before the electronics in the fixture can kick-start it again. Wait 5 to 10 minutes before powering up your Chauvet Light Fixture.
How to resolve auto shut off on Chauvet Light Fixture?
Check the fan thermal switch reset.
Lists all items provided with the DMX-800 Constellation fixture.
Instructions for safely unpacking the fixture and checking for damage.
Details on voltage selection and proper AC power connection.
Contact information for Chauvet Lighting for general inquiries.
Essential safety guidelines for operating and maintaining the fixture.
Highlights the main capabilities and specifications of the fixture.
Overview of DMX channel assignments for 19 and 13-channel modes.
Step-by-step guide for installing the fixture's lamp.
Information on suitable data cables for linking fixtures.
Details on DMX connector configuration and pin assignments.
Guide for converting between 3-pin and 5-pin DMX connectors.
Step-by-step instructions for creating a DMX serial data link.
Guidelines on fixture placement and mounting positions.
Safety advice and best practices for rigging the fixture.
How to use the buttons and LCD display to control the fixture.
Visual guide to the fixture's menu structure and navigation.
Detailed explanation of each menu option and its function.
How to operate the fixture in Sound-Active and Auto modes.
Setup and operation for linking multiple fixtures without a controller.
Detailed breakdown of DMX channel functions for 19-channel mode.
Detailed breakdown of DMX channel functions for 13-channel mode.
Specific DMX values for controlling gobo selection and rotation.
Contact details for technical assistance and service.
Basic explanation of the DMX-512 protocol for lighting control.
Recommendations for cleaning and maintaining the fixture.
Steps for returning merchandise and filing damage claims.
Power| switch-selectable power settings | 110V 60Hz AC or 230V 50Hz |
|---|---|
| power consumption | 840W Max |
| inrush power | 936W |
Light Source| lamp type | HMI 575W Lamp |
|---|---|
| approved lamp Osram HMI575/GS | 1000 hr, 6000K, 575W |
| approved lamp Philips MSI-575/2 | 1000 hr, 7000K, 575W |
Photo Optic| beam angle each beam | 12° |
|---|---|
| beam angle entire unit | 73° |
| illuminance at 1m | 9, 784 fc (105, 276 lux) |
Thermal| maximum ambient temperature | 95°F (35°C) |
|---|---|
| main fuse | 20mm Glass 15A 250V Fast Blow |
| secondary fuse | 20mm Glass 3A 250V Fast Blow |
Weight and Dimensions| length | 33.5 in (850 mm) |
|---|---|
| width | 31.5 in (800 mm) |
| height | 11.8 in (300 mm) |
| weight | 99.2 lbs (45 kg) |
