Chauvet LED PAR 38-18B User Manual

3000 N 29
th
Ct, Hollywood, FL 33020 U.S.A.
(800) 762-1084 – (954) 929-1115
FAX (954) 929-5560
www.chauvetlighting.com
LED PAR 38-18B
LED PAR 38-18C
User Manual
Snapshot
Use on Dimmer
Outdoor Use
Sound Activated
DMX
Master/Slave
Auto-ranging
Power Supply
Replaceable Fuse
User Serviceable
Duty Cycle

Chauvet LED PAR 38-18B Specifications

Power

auto-ranging power supply	100~240 VAC, 50/60 Hz
power consumption at 120 VAC	22 W (0.4 A) max
power consumption at 230 VAC	22 W (0.2 A) max
fuse	T 1 A, 250 V

Light Source

led power	1 W
led current	350 mA
led lifespan	50, 000 hrs

Photo Optic

luminance at 1 m	4, 000 lux
beam angle	16°
field angle	32°

Operating Environment

maximum ambient temperature	104° F

Weight and Dimensions

length	9.3 in
width	8.8 in
height	11.4 in
weight	3.7 lbs
