90
15.3.5. CURRENT SENSOR CHARACTERISTICS (AFTER LINEARIZATION)
Sensor errors are offset by a typical correction inside the device. This typical correction, applied to the phase and amplitude,
depends on the type of sensor connected (detected automatically) and the gain in the current acquisition channel used.
The RMS current measurement error and phase error are additional errors (which must therefore be added to the device errors),
indicated as influences on the calculations carried out by the analyser (powers, energies, power factors, tangents, etc.).
Type of sensor RMS current (Arms) Maximum error for Arms
Maximum error for Φ
AmpFLEX™ A193
6,500 A
[10 A ; 100 A[ ±(3 %) ±(1°)
[100 A ; 6,500 A] ±(2 %) ±(0.5°)
MiniFLEX MA193
6,500 A
[10 A ; 100 A[ ±(3 %) ±(1°)
[100 A ; 6,500 A] ±(2 %) ±(0.5°)
C193 clamp
1,000 A
[1 A ; 3 A[
±(0.8 %)
-
[3 A ; 10 A[ ±(1°)
[10 A ; 100 A[ ±(0.3 %) ±(0.5°)
[100 A ; 1,200 A] ±(0.2 %) ±(0.3°)
PAC93 clamp
1,000 A
[1 A ; 10 A[
±(1.5 % + 1 A)
-
[10 A ; 100 A[ ±(2°)
[100 A ; 800 A[ ±(3 %)
±(1.5°)
[800 A ; 1,200 A] ±(5 %)
MN93 clamp
200 A
[0.5 A ; 2 A[
±(3 % + 1 A)
-
[2 A ; 10 A[ ±(6°)
[10 A ; 100 A[ ±(2.5 % + 1 A) ±(3°)
[100 A ; 240 A] ±(1 % + 1 A) ±(2°)
MN93A clamp
100 A
[100 mA ; 300 mA[
±(0.7 % + 2 mA)
-
[300 mA ; 1 A[ ±(1.5°)
[1 A ; 120 A] ±(0.7 %) ±(0.7°)
E3N clamp 100A
Sensitivity 10 mV/A
[0 A ; 40 A[ ±(2 % + 50 mA)
±(0.5°)
[40 A ; 100 A] ±(5 %)
E3N clamp 10A
Sensitivity 100 mV/A
[0 A ; 10 A] ±(1.5 % + 50 mA) ±(1°)
MN93A clamp
5 A
[5 mA ; 50 mA[ ±(1 % + 0.1 mA) ±(1.7°)
[50 mA ; 500 mA[ ±(1 %)
±(1°)
[500 mA ; 6 A] ±(0.7 %)
5 A adapter
[5 mA ; 50 mA[ ±(1 %) ±(1°)
[50 mA ; 6 A] ±(0.5 %) ±(0°)
