PART LIST FOR THE G83 (700-200) LOCKBOLT POWER TOOL ASSEMBLY
THIS TOOL IS OBSOLETE; SEE G83A FOR REPLACEMENT
ITEM NO. PART NUMBER DESCRIPTION QTY
700-216 SUB-ASSEMBLY, HANDLE
1 700-229 HANDLE, MACHINED 1
2 P-653 O-RING (.691, .551, .070) 4
3 700B73 SLEEVE, VALVE 1
4 700A67 SPRING 1
5 P-829* O-RING, DISOGRIN (.504, .364, .070) 3
70 700A15 SUB-ASSEMBLY, VALVE SPOOL
6 700D15-2 SPOOL, VALVE 1
7 700A18 FILTER, AIR VALVE 1
8 700A69 SCREW, METERING 1
9 P-834* O-RING, DISOGRIN (.816, .676, .070) 2
10 700A16 PLUG, VALVE 1
11 700A17 MUFFLER 1
12 P-279 RING, RETAINING (INT..906 DIA.) 1
71 700-219 POWER PISTON & ROD SUB-ASSEMBLY
13 700A10** ROD, POWER PISTON 1
14 702A12** STOP, PISTON 1
15 700B118** PISTON, POWER 1
16 700-202** CAP, PISTON ROD 1
17 P-830 O-RING (.629, .489, .070) 1
18 P-833 O-RING (1.068, .862, .103) 2
19 700C122 CYLINDER, POWER 1
20 700-205 PISTON, RETURN 1
21 P-508 O-RING (.755, .549, .103) 1
22 P-1367 SPRING 1
23 P-838* O-RING, DISOGRIN (.568, .362, .103) 2
24 P-115 RING, BACK-UP (.551, .375, .088) 2
25 P-727 O-RING (1.318, 1.112, .103) 1
26 700B93 PLUG, PACKING 1
27 P-731 RING, BACK-UP (3.365, 3.125, .120) 2
28 P-730 RING, QUAD (3.387, 3.109, .139) 1
29 700B6 PISTON, AIR 1
30 P-737 NUT, CONELOK, 1/4-20 1
31 P-725 O-RING (3.129, 2.989, .070) 1
32 700B4 BASE, HANDLE 1
33 P-735 RING, RETAINING (INT. 3.500 DIA.) 1
34 700B109 COVER, BASE 1
35 P-736 RING, RETAINING (EXT. 2.250 DIA.) 1
36 703A33 ASSEMBLY, TRIGGER (INCLUDES P-223) 1
37 P-223 O-RING (.285, .145, .070) 1
700-213 SUB-ASSEMBLY, HEAD CYLINDER
38 700-204 CYLINDER, RETURN 1
72 700-214 SUB-ASSEMBLY, RELIEF VALVE
39 700-218 SEAT, SPRING 1
40 P-1366 SPRING 1
41 P-383 O-RING (.441, .301, .070) 1
42 700-215 SEAT, BALL 1
43 P-688 BALL (3/32 DIA.) 1
44 700-217 PISTON, VALVE 1
45 P-111 O-RING (.379, .239, .070) 1
46 P-573 SCREW, BUTTON HD CAP, 10-32 X 1/4 3
47 P-572 STAT-O-SEAL (.430, .180, .125) 3
48 700-203 CYLINDER, HEAD 1
49 P-568 O-RING (.818, .612, .103) 2
50 P-242 RING, BACK-UP (.801, .625, .088) 1
51 700-210 PISTON, HEAD 1
52 P-932 RING, BACK-UP (1.242, 1.000, .121) 2
53 P-113 O-RING (1.262, .984, .139) 1
54 P-107 O-RING (1.074, .796, .139) 1
55 P-108 RING, BACK-UP (1.054, .812, .121) 1
56 P-1373 O-RING (1.403, 1.171, .116) 1
57 700-212 CAP, END 1
58 P-880 RING, RETAINING, NON-STANDARD 1
59 703A13 FITTING, DEFLECTOR 1
60 530A16 DEFLECTOR 1
73 700-211 SUB-ASSEMBLY, ADAPTER
61 700-256 SLEEVE, LOCKING 1
62 700-255 EXTENSION, HEAD 1
63 700-257 SPACER, ADAPTER 3
64 P-1372 SPRING 1
65 P-957 RING, RETAINING (EXT Ø.875) 1
66 P-699 RING, RETAINING (INT Ø1.125) 1
67 P-832* O-RING, DISOGRIN (.379, .239, .070) 1
68 700-230 GASKET 1
69
P-27
SCREW, SOCKET HEAD CAP, 8-32 X 1/2
4
*No substitutions.
** Not sold separately
*** Included in Air Piston Kit 700A115
