Cherry G704B - Part List for G704 B Riveter

10
ITEM NO. DESCRIPTION QTY.
704B35 SUB-ASSEMBLY, HEAD
704C19 SUB-ASSEMBLY, HEAD CYLINDER
1 704C18 CYLINDER, HEAD
1
1A 704B2-2 FITTING, NOSE
1
2 P-701 O-RING (.629, .489, .070)
2
3 P-998 RING, BACK-UP (.609, .503, .053)
1
4 704C3 PISTON, HEAD
1
5 P-931 O-RING (1.193, .987, .103)
1
6 P-1000 RING, BACK-UP (1.176, 1.000, .088)
1
7 P-870 O-RING (1.191, 1.051, .070)
2
8 P-112 O-RING (.504, .364, .070)
1
9 704B4 CAP, HEAD CYLINDER
1
10 P-880 RING, RETAINING (NON-STANDARD)
1
11 703A13 FITTING, DEFLECTOR
1
12 530A16 DEFLECTOR, PIN
1
13 P-572 STAT-O-SEAL (.443, .180, .132)
1
14 P-573 SCREW, BUTTON HD. SOC. 10-32 x 1/4
1
704-086 SUB-ASSEMBLY, HANDLE
15 P-838** O-RING, DISOGRIN (.568, .362, .103)
2
16 P-115 RING, BACK-UP (.551, .375, .088)
2
17 P-727 O-RING (1.318, 1.112, .103)
1
18 700B93 PLUG, PACKING
1
19 P-731 RING, BACK-UP (3.387, 3.109, .139)
2
20 P-730 RING, QUAD (3.387, 3.109, .139)
1
21 700B6 PISTON, AIR
1
22 P-737 NUT, CONELOK, 1/4-20
1
23 P-725 O-RING (3.129, 2.989, .070)
1
24 700B4 BASE, HANDLE
1
25 P-735 RING, RETAINING (INT. Ø3.500)
1
26 700D107 COVER, BASE
1
27 P-736 RING, RETAINING (EXT. Ø2.250)
1
28 703A33 ASSEMBLY, TRIGGER (INCLUDES P-223)
1
29 P-223 O-RING (.285, .145, .070)
1
30 703A11 HANDLE
1
31 700-247 CYLINDER, POWER
1
32 P-833** O-RING, DISOGRIN (1.068, .862, .103)
2
33 P-739 RING, BACK-UP (.614, .518, .056)
1
34 P-830** O-RING, DISOGRIN (.629, .489, .070)
1
35 700-248 ROD, POWER PISTON
1
36 P-653 O-RING (.691, .551, .070)
4
37 700B96 SLEEVE, VALVE
1
38 700A67 SPRING
1
39 P-829** O-RING, DISOGRIN (.504, .364, .070)
4
52 700A94 SUB-ASSEMBLY, VALVE SPOOL
40 700B95 SPOOL, VALVE
1
41 700A18 FILTER
1
42 700A69 SCREW, METERING
1
43 P-834** O-RING, DISOGRIN (.816, .676, .070)
2
44 700A16 PLUG, VALVE
1
45 700A17 MUFFLER
1
46 P-279 RING, RETAINING (INT. Ø.906)
1
47 P-832** O-RING, DISOGRIN (.379, .239, .070)
1
48 700A22 GASKET
1
49 P-27 SCREW, SOC. HD. CAP, 8-32 x 1/2
4
50 670A20* BAG, MANDREL CATCHER
1
51 P-948* HOSE, AIR
1
*Not furnished with riveter. Must be ordered separately if desired.
**No substitutions.
Note: Use Loctite #271 or equivalent when assembling items 1 and 1A.
All dimensions in inches.
PART LIST FOR THE G704B (704
-
087) CHERRYMAX RIVETER ASSEMBLY
