5
HOW TO USE THE G704B
After selecting the proper pulling head and attaching it securely to the G704B, connect the air line to the tool. Insert the rivet stem
into the pulling head until the head of the rivet is in contact with the pulling head sleeve. This will ensure full engagement between
the jaws and the rivet stem and will prevent slippage.
Once the rivet stem is inserted in the H701B-456 pulling head, the rivet must be installed. The “stem stop” in the pulling head will
prevent the mandrel from moving back out the front of the head.
Insert the rivet into the application and pull the trigger to activate the tool. Upon the release of the trigger, the stem will eject to the
rear of the tool (when using the H701B-456 straight pulling head). When using the H781-456 offset pulling head, the stem will eject
through the offset pulling head to the rear. When using the H753A-456 right angle pulling head, the stem will eject out the front.
MAINTENANCE AND REPAIR
The G704B has been manufactured to give maximum service with minimum care. In order that this may be accomplished, the fol-
lowing recommendations should be followed:
1. The hydraulic system should be full of fluid and free from air at all times.
2. Keep excessive moisture and dirt out of air supply to prevent wear of air valve, air cylinder and air piston.
3. Tool should be routinely inspected for oil leaks.
Use automatic transmission fluid Type “A” (no substitutes). CHERRY recommends using Dexron® III ATF.
DEXRON III OIL SAFETY DATA
FIRST AID
Skin: Wash thoroughly with soap and water as soon as possible. Casual contact requires no immediate
attention. If irritation develops, consult a physician.
Ingestion: Seek medical attention immediately. DO NOT INDUCE VOMITING.
Eyes: Flush with copious amounts of water. If irritation develops, consult a physician.
Inhalation: No significant adverse health effects are expected to occur on short term exposure. Remove from contaminated area.
Apply artificial respiration if needed. If unconscious, consult physician.
FIRE
Suitable extinguishing media: CO
2
, dry powder, foam or water fog. DO NOT use water jets.
ENVIRONMENT
Waste Disposal: In accordance with local, state and federal regulations.
Spillage: Prevent entry into drains, sewers and water courses. Soak up with diatomaceous earth or other inert material. Store in
appropriate container for disposal.
HANDLING
Eye protection required. Protective gloves recommended. Chemically resistant boots and apron recommended. Use in well ventilated area.
COMBUSTIBILITY
Slightly combustible when heated above flash point. Will release flammable vapor which can burn in open or be explosive in
confined spaces if exposed to source of ignition.
STORAGE
PROPERTIES
Specific gravity
0.863
Weight per gallon
7.18 lbs.
Open flashpoint
>200°C (392°F)
