ELECTRICAL CONNECTIONS
TECHNICAL FEATURES
There are two versions of the Windtec sensor:
- Windtec: Wind sensor
- Windtec Lux: Wind & Sun sensor
Both models are supplied with 230V AC and communicate with the motors by radio
frequency (433.92 MHz). The Windtec and Windtec Lux sensors are compatible with the
Blue Wave RX range motors.
windtec
windtec lux
Light blue
Brown
windtec
wind sensor
windtec lux
wind & sun sensor
POWER SUPPLY
(V) / (Hz)
230 / 50 433,92 7,5 - 45
230 / 50 433,92 7,5 - 45
2,5 - 100
RADIO
FREQUENCY
(MHz)
SETTING WIND
SENSOR
(km/h)
REGOLAZIONE
SENSORE LUCE
(klux)
FUNTIONS
