02 - POWER ASSY-POWER ACCESSORY
02–25
Crankshaft connecting rod mechanism
No. Part No. Station No. Station Name
Labour
Time
10 E4G16-1004110AC T19E4G10041102751 Remove and reinstall 1 E4G16 connecting rod
assemblie
20
Ex: T19E4G10090102701 Remove and reinstall oil pan assy 100
Ex: T19E4G10030102751 Remove and reinstall E4G15C cylinder head assy 160
Ex: T19E4G10070802751 Remove and reinstall timing chain assy 40
Ex: T19E4G10070832701 Remove and reinstall timing chain cover 120
T19E4G10041102752 Remove and reinstall 2 E4G16 connecting rod
assemblies
30
Ex: T19E4G10090102701 Remove and reinstall oil pan assy 100
Ex: T19E4G10030102751 Remove and reinstall E4G15C cylinder head assy 160
Ex: T19E4G10070802751 Remove and reinstall timing chain assy 40
Ex: T19E4G10070832701 Remove and reinstall timing chain cover 120
T19E4G10041102753 Remove and reinstall 3 E4G16 connecting rod
assemblies
40
Ex: T19E4G10090102701 Remove and reinstall oil pan assy 100
Ex: T19E4G10030102751 Remove and reinstall E4G15C cylinder head assy 160
Ex: T19E4G10070802751 Remove and reinstall timing chain assy 40
Ex: T19E4G10070832701 Remove and reinstall timing chain cover 120
T19E4G10041102754 Remove and reinstall 4 E4G16 connecting rod
assemblies
50
Ex: T19E4G10090102701 Remove and reinstall oil pan assy 100
Ex: T19E4G10030102751 Remove and reinstall E4G15C cylinder head assy 160
Ex: T19E4G10070802751 Remove and reinstall timing chain assy 40
Ex: T19E4G10070832701 Remove and reinstall timing chain cover 120
11 E4G16-1005015 T19E4G10050152751 Remove and reinstall crankshaft thrust washer 0
Ex: T19E4G0000E843651 Disassemble and reassemble E4G15C engine assy 350
Ex: T19E4G0000E842701 Remove and reinstall E4G15C engine assy 600
12 481H-1005030BA T19E4G10050302751 Remove and reinstall RR oil seal - crankshaft 20
Ex: T19E4G10051102751 Remove and reinstall flywheel assy (with additional
wheel, signal wheel)
50
Ex: T19M1720000082701 Remove and reinstall transmission assy 350
13 E4G16-1002050AB T19E4G10020502751 Remove and reinstall 1-4 piston cooling nozzle 10
Ex: T19E4G0000E843651 Disassemble and reassemble E4G15C engine assy 350
Ex: T19E4G0000E842701 Remove and reinstall E4G15C engine assy 600
14 684V-1002027 T19E4G10020272751 Remove and reinstall main bearing cap locating pin 20
Ex: T19E4G0000E843651 Disassemble and reassemble E4G15C engine assy 350
Ex: T19E4G0000E842701 Remove and reinstall E4G15C engine assy 600
