Chery T19 2020 - Reverse Mechanism

03 - TRANSMISSION SHIFT MECHANISM
03–25
Reverse mechanism
No. Part No. Station No. Station Name
Labour
Time
01 5MF17D-1702040 T19M1717020402751 Remove and reinstall reverse swing arm assy 0
Ex: T19M1717010152751 Remove and reinstall transmission housing 110
Ex: T19M1720000082701 Remove and reinstall transmission assy 350
02 5MF17J-1701080 T19M1717010802751 Remove and reinstall reverse intermediate gear assy 0
Ex: T19M1717010152751 Remove and reinstall transmission housing 110
Ex: T19M1720000082701 Remove and reinstall transmission assy 350
03 5MF17J-1702014 T19M1717020142701 Remove and reinstall reverse light switch wire harness
bracket
10
04 7A160-1702045 T19M1717020452751 Remove and reinstall reverse swing arm bracket gasket 0
Ex: T19M1717010152751 Remove and reinstall transmission housing 110
Ex: T19M1720000082701 Remove and reinstall transmission assy 350
05 7A160-1702047 T19M1717020472751 Remove and reinstall reverse swing arm bracket fixing
bolt
0
Ex: T19M1717010152751 Remove and reinstall transmission housing 110
Ex: T19M1720000082701 Remove and reinstall transmission assy 350
06 S170F01-1701094 T19M1717010942751 Remove and reinstall reverse intermediate gear shaft
fixing bolt
0
Ex: T19M1717010152751 Remove and reinstall transmission housing 110
Ex: T19M1720000082701 Remove and reinstall transmission assy 350
07 7A160-1701096 T19M1717010962701 Remove and reinstall aluminum sealing ring 10
08 S170F01-1701092 T19M1717010922751 Remove and reinstall reverse intermediate gear shaft 0
Ex: T19M1717010152751 Remove and reinstall transmission housing 110
Ex: T19M1720000082701 Remove and reinstall transmission assy 350
09 S170F01-1701088 T19M1717010882701 Remove and reinstall reverse stopper nylon washer 20
10 119000027AA T19M1790000272751 Remove and reinstall hydraulic release bearing 20
Ex: T19M1720000082701 Remove and reinstall transmission assy 350
11 5MF17J-3719100 T19M1737191002701 Remove and reinstall reverse switch assy 20
