Chery T19 2020 - Steering System

04 - CHASSIS
04–5
Steering system
No. Part No. Station No. Station Name
Labour
Time
01 201000094AA T19KKK10000942751 Remove and reinstall mechanical steering gear with tie
rod assy
130
Ex: T19KKK10000001200 Four-wheel alignment 180
02 201000128AA T19KKK10001282751 Remove and reinstall OTR ball pin assy LH 30
Ex: T19KKK10000001200 Four-wheel alignment 180
03 201000126AA T19KKK10001262751 Remove and reinstall tie rod boot LH 10
Ex: T19KKK10001282751 Remove and reinstall OTR ball pin assy LH 30
Ex: T19KKK10000001200 Four-wheel alignment 180
T19KKK10001262761 Remove and reinstall tie rod boot RH 10
Ex: T19KKK10001292751 Remove and reinstall OTR ball pin assy RH 30
Ex: T19KKK10000001200 Four-wheel alignment 180
04 201000096AA T19KKK10000962751 Remove and reinstall power steering column with
intermediate shaft assy
80
Ex: T19KKK40001432751 Remove and reinstall steering wheel assy 30
Ex: T19KKK70001842701 Remove and reinstall driver airbag assy 20
05 201000125AA T19KKK10001252751 Remove and reinstall INR tie rod assy LH 20
Ex: T19KKK10001262751 Remove and reinstall tie rod boot LH 10
Ex: T19KKK10001282751 Remove and reinstall OTR ball pin assy LH 30
Ex: T19KKK10000001200 Four-wheel alignment 180
T19KKK10001252761 Remove and reinstall INR tie rod assy RH 20
Ex: T19KKK10001262761 Remove and reinstall tie rod boot RH 10
Ex: T19KKK10001292751 Remove and reinstall OTR ball pin assy RH 30
Ex: T19KKK10000001200 Four-wheel alignment 180
06 201000129AA T19KKK10001292751 Remove and reinstall OTR ball pin assy RH 30
Ex: T19KKK10000001200 Four-wheel alignment 180
