03 - TRANSMISSION SHIFT MECHANISM
03–5
CVT18 transmission
No. Part No. Station No. Station Name
Labour
Time
18 025CHA-1506400 T19C1815064002701 Remove and reinstall filter assy - oil pump 70
19 025CHA-1509103 T19C1815091032751 Remove and reinstall o-ring - input shaft to hydraulic
torque converter
30
Ex: T19C1815011202751 Remove and reinstall hydraulic torque converter assy 10
Ex: T19C1810000252701 Remove and reinstall transmission assy 400
20 6AF28A-1507072 T19C1815070722701 Remove and reinstall O-ring 40
21 6AF28A-1507082 T19C1815070822701 Remove and reinstall O-ring 30
22 0CF18A-1501111GA T19C1815011112701 Remove and reinstall oil draining guide tube 20
23 025CHA-1506531 T19C1815065312751 Remove and reinstall gasket - OTR filter and
transmission housing
0
Ex: T19C1815065012701 Remove and reinstall OTR filter housing 60
24 025CHA-1506510 T19C1815065102751 Remove and reinstall OTR filter assy 0
Ex: T19C1815065012701 Remove and reinstall OTR filter housing 60
To Next Page
