Training Center of After-Sales Department Chery International
2. PEPS system
48
5. Notices in operation and maintenance
Operation procedure of replace TCU (Only for CVT car)
1. Read the VIN by scanner from ECU, PEPS module, TCU, and apply the PIN from CHERY.
2. After the new TCU is successfully installed, press ignition (IG) switch to supply power.
3. Enter the matching interface, select ”Program TCU” menu, and input the VIN and PIN as
scanner interface reminding. After successfully program TCU, the scanner screen shows ”Program
TCU succeed”.
4. With the car power supply in IGN mode, depress the brake pedal to check whether the gearshift
lever can be easily shifted from P to other gear. If yes, the replacement is successful, otherwise, it
is failed.
