A/C System
119
A/C display panel
Note: A part of symbols of A/C system are displayed in the figure above. When the A/C system runs, some symbols will not appear.
The related symbol appears only in case of the corresponding run mode. So, these symbols represent the current run mode of A/C
System, which will be described in the following.
Temp Display Defrost
Internal
Cycle
Face
Foot
AUTO Mode
External
Cycle
COOL mode
Blower
Position
Blower
Run
