Capacity and Specification Parameters
191
Engine Information
Model 4G64S4M
Type
Vertical four-cylinder, four-stroke, water cooling, overhead camshaft, 16 valves,
transverse mounted, and multipoint sequence injection
Cylinder Diameter mm 86.5
Piston Travel mm 100
Displacement ml 2,350
Compression Ratio 9
Rated power (net power)
kW
95
Rated RPM r/min 5,500
Max. Torque N.m 198
Max. Speed r/min 3,000
Min. Fuel Consumption
g/kw.h
260
** The adjustment or check begins only more than 5 minutes after the engine stops operating.
