Steps for assembling:
1.
Loosen the A.B.C. three screws from the blade guide. And take away the part "D"
2.
To lock the vertical cutting plate stand on the valve.
3.
To put the plate on the guide and vertical cutting plate stand, then lock the A.B.C. three screws.
4.
Please operate the vertical cutting.
5.
Use the miter gauge in the work table grooves to obtain any angle up to 45 degree either left or
right.
CAUTION-The use of any other accessories may be hazardous.
CAUTION-Always use push sticks particularly when cutting small pieces.
The manual of V shape fixed plate
7
