Black plate (36,1)
Chevrolet Express Owner Manual - 2012 - crc - 11/11/11
10-36 Vehicle Care
To prevent headlamp vibration
and shortened bulb life, be sure
to insert the headlamp assembly
tabs in the slots at the lower
portion of the housing.
Sealed‐Beam Headlamp
A. Headlamp retainer screws
B. Headlamp retainer
C. Sealed‐beam headlamp bulb
1. Remove the four screws (A)
from the headlamp retainer (B).
Pull the retainer (B) out and set
it aside.
2. Pull the bulb (C) forward to gain
access to the electrical
connector.
3. Disconnect the electrical
connector (B) and remove the
headlamp bulb (A).
4. Reverse Steps 1 through 3 to
reinstall the headlamp.
Front Turn Signal,
Sidemarker, and Parking
Lamps
A. Front Parking and Turn
Signal Lamp
B. Front Sidemarker Lamp
