Vehicle Care 10-41
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.
Mini Fuse Usage
3
Right Stop/Turn
Trailer
4 Spare
5 Spare
6
Fuel System
Control Module
Ignition
7
Body Control
Module 5
8
Body Control
Module 7
9
Body Control
Module 4
10
Instrument Panel
Cluster
11 Trailer Wiring
12 Spare
13 Spare
14 Windshield Washer
16 Horn
