Cheyenne Sol Nova - 3 Scope of Delivery; 4 Product Info about the SOL Nova; Technical Data; Operating Conditions

24
EN
Symbol Meaning
Temperature limit
Humidity limit
Store in a dry place
Fragile
Cannot be use if packaging is
damaged
Do not reuse!
Dispose of properly as used
electronic equipment!
3 Scope of delivery
1 Cheyenne SOL Nova
1 Power cable
1 Cable adapter (6.3 mm jack to 3.5 mm
socket)
1 Operating instructions
4 Product info about the SOL
Nova
The Cheyenne SOL Nova is a high-
performance device and is much quieter
and vibrates less than conventional
tattooing machines. It has powerful skin
piercing power and frequency.
4.1 Technical data
Nominal voltage 5 to 12.6 V DC
Power intake 3 W
Start-up current
Max. 2.5 A for
max. 200 ms
Piercing frequency 25 to 150 Hz
Stroke 3.5 mm
Needle protrusion 0 to 4.0 mm
Electrical connection 3.5 mm jack
Drive Brushless DC
motor
Operating mode Continuous
operation
Diameter 33 mm
Length 102 mm
Weight Approx. 150 g
Sound emission
pressure level
Max. 70 dB (A)
Total vibration Max. 2.5 m/s²
4.2 Operating conditions
Ambient temperature +10 to +35°C
Relative humidity 30 to 75%
4.3 Accessories
The following accessories can be
purchased from your local specialist
retailer:
• Cheyenne safety cartridges
• Cheyenne Power Units
• Cheyenne foot switch
• Handles
• Cable adapters
Protective hoses must have a diameter of
34 to 40 mm. This corresponds to a hose
width of 54 to 63 mm.
Cheyenne SOL Nova
