Chicago Pneumatic CP7732C - Air Diagram

Air Diagram
Model
Drive
Torque
Free speed
Dimension
L x W x H
Air Consumption
Weight Inner Hose Dia. Air Inlet
Sound pressure
L
pA
Sound power
L
wA
Vibrations
Working Max Average At load a
hd
K
W
L
1 2 3 4 5 6 7 8 9 10
[inch]
[ft.lbs]
[Nm]
[min-1]
[inch]
[mm]
[SCFM]
[Nl/s]
[lb]
[kg]
[inch]
[mm]
[inch]
[dB(A)] [dB(A)] [m/s²] [m/s²]
CP7732C
1/2"
52-285
70-387
460
625
9410
4.3*2.6*7.5
108*65*190
5.5
2.6
22
10.2
2.2
1.0
3/8"
10
1/4" NPT
95,50 106,50 10,80 1,42
H
A
C
ON/OFF
L
W
FIG. 02
FIG. 03
FIG. 01
B
