- 18 -
LOG list
The unit will keep an event log of the latest 30 events.
Events are:
– shutdowns
– service timer 1/2 reset
– unit type changes
Together with each event, the running hours at the time of
the event will be stored.
Remort Start operation
Installation wirings:
– X25.1 & X25.2 to be wired for the remote start switch.
– X25.3 & X25.4 to be wired for the remote contactor (open/
close).
Fail classes
All the activated alarms of the Qc1002™ have their own
pre-defined fail class.
All alarms are enabled according to one of these three
statuses:
– disabled alarm, no supervision of alarm (OFF).
– enabled alarm, supervision of alarm all the time (ON).
– running alarm, only supervision when the machine is
running (RUN).
1 Controller type
2 Event number
3Event
4 Running hours
Time: 00001h
EVENT LOG #04
Water
Qc1002
1
3
4
2
