- 34 -
Technical specifications
Technical specifications for CPG 20 Kubota
Readings on gauges
Settings of switches
Specifications of the engine/alternator/unit
Gauge Reading Unit
Ammeter L3 (P3) Below max. rating A
Voltmeter (P4) Below max. rating V
Switch Function Activates at
Engine oil pressure Shut down 0.5 bar
Engine coolant temperature Shut down 105°C
60 Hz
Reference conditions 1)
Rated frequency 60 Hz
Rated speed (optional)
1800 rpm
Generator service duty
PRP
Absolute air inlet pressure
100 kPa
Relative air humidity
30%
Air inlet temperature
25°C
Limitations 2)
Maximum ambient temperature 50°C
Altitude capability
4000 m
Maximum relative air humidity
85%
Minimum starting temperature unaided
-18°C
Minimum starting temperature aided (optional)
-25°C
Performance data 2) 3) 5)
Rated active power (PRP) 1ph 17.3 kW
Rated active power (PRP) 3ph N/A
Rated power factor (lagging) 1ph
1.0 cos
Rated PRP power 1ph
17.3 kVA
Rated PRP power 3ph
N/A
Rated voltage 1ph
240 V
Rated current 1ph
72.1 A
Performance class (acc.ISO 8528-5:1993)
G2
Single step load acceptance (0-PRP)
17.3 kW
100%
Frequency droop
< 5%
isochronous
