- 36 -
Electical system
12 Vdc
Emission compliance
iT4
Power circuit
Circuit-breaker, 1-ph. (optional)
Number of poles
2
Thermal release It (thermal release is higher at 25°C)
80 A
Magnetic release Im
3..5xIn
Unit
Dimensions (LxWxH) 2097.1 x 950 x 1141 mm
Weight net mass
709 kg
Weight wet mass
824 kg
Notes
1) Reference conditions for engine performance to ISO 3046-1.
2) See derating diagram or consult the factory for other conditions.
3) At reference conditions unless otherwise stated.
4) Rating definition (ISO 8528-1):
LTP: Limited Time Power is the maximum electrical power which a generating set is capable of delivering (at variable load), in the event of a utility power failure (for up to
500 hours per year of which a maximum of 300 hours is continuous running). No overload is permitted on these ratings. The alternator is peak continuous rated (as defined
in ISO 8528-3) at 25°C.
PRP: Prime Power is the maximum power available during a variable power sequence, which may be run for an unlimited number of hours per year, between stated main-
tenance intervals and under the stated ambient conditions. A 10% overload is permitted for 1 hour in 12 hours. The permissible average power output during a 24h period
shall not exceed the stated load factor of 80%.
5) Specific mass fuel used: 0.86 kg/l.
Derating
Height
(m)
Temp eratu re
(°C)
0 5 10 15 20 25 30 35 40 45 50
0 100 100 100 100 100 100 100 95 95 90 90
500 100 100 100 95 95 95 90 90 85 85 85
1000 95 90 90 90 90 85 85 85 80 80 75
1500 85 85 85 85 80 80 80 75 75 75 70
2000 80 80 80 75 75 75 75 70 70 70 65
2500 75 75 75 70 70 70 65 65 65 65 60
3000 70 70 65 65 65 65 60 60 66 60 55
3500 65 65 60 60 60 60 60 55 55 55 50
Technical specifications for CPG 20 Kubota
