Chicago Pneumatic CPG 25 - CPG 25 Kubota Specifications

- 37 -
Technical specifications for CPG 25 Kubota
Readings on gauges
Settings of switches
Specifications of the engine/alternator/unit
Gauge Reading Unit
Ammeter L3 (P3) Below max. rating A
Voltmeter (P4) Below max. rating V
Switch Function Activates at
Engine oil pressure Shut down 0.5 bar
Engine coolant temperature Shut down 105°C
60 Hz
Reference conditions 1)
Rated frequency 60 Hz
Rated speed (optional)
1800 rpm
Generator service duty
PRP
Absolute air inlet pressure
100 kPa
Relative air humidity
30%
Air inlet temperature
25°C
Limitations 2)
Maximum ambient temperature 50°C
Altitude capability
4000 m
Maximum relative air humidity
85%
Minimum starting temperature unaided -2
°C
Minimum starting temperature aided (optional)
-25°C
Performance data 2) 3) 5)
Rated active power (PRP) 3ph 18.6 kW
Rated active power (PRP) 1ph (optional)
17.3 kW
Rated power factor (lagging) 3ph
0.8 cos 
Rated power factor (lagging) 1ph (optional)
1.0 cos 
Rated PRP power 3ph
23.3 kVA
Rated PRP power 1ph (optional)
17.3 kVA
Rated voltage 3ph. line to line
480 V
Rated voltage 3ph. line to line lower voltage
240 V
Rated voltage 1ph (optional)
240 V
Rated current 3ph.
28.6 A
Rated current 3ph. lower voltage
56.1 A
Rated current 1ph. (optional)
72.1 A
Performance class (acc.ISO 8528-5:1993) (optional)
G2
Single step load acceptance (0-PRP)
18.6 kW
100%
