Chicago Welding 98871 - Parts List

Page 31For technical questions, please call 1-800-444-3353.SKU 98871
SAFETYSERVICE BASIC WELDINGWELDING TIPS SETUP
Parts List
Part Description Q’ty
1a BackHandle 1
1b Front Handle 1
1c Trigger 1
1d Handle Lock Ring 1
1e Gun Tube 1
2b .9 mm Contact Tip 1
3 Nozzle 1
4 Wire Liner 1
5 Gun Cable Clamp A 1
6
GunCableClampB 1
7a Power Switch 1
7b Current Switch (MIN/MAX) 1
8 Cover Latch 1
9 Wire Speed Dial 1
10 Nut 1
11
FeedControlCircuitBoard 1
12 Right Side Panel 1
13 Left Side Panel 1
14
BaseFrame 1
15 Foot 4
16 Washer 4
17 Screw, ST4.2*13 4
18
TransformerBracket 2
19 Thermostat 1
20 Transformer 1
21 Middle Partition 1
22 Overload Indicator 1
23 Wire Feed Assembly 1
Part Description Q’ty
24 Spool Spring 1
25 Wing Nut, M6 1
26 Spool Retaining Nut 1
27 Wire Spool 1
28 Spool Spindle 1
29 Screw, ST4.2*25 1
30 Handle 1
31 Cover 1
32 Power Cord 1
33 Ground Cable 1
34 Feed Roller 1
35
FeedBearing 1
36 Feed Swing Arm 1
37 Feed Tensioner 1
38 Face Shield (shade #10) 1
39
WireBrush/ChippingHammer 1
40 Washer 1
41 Nut 1
42 Bolt 1
43 Multi-wrench (for Contact Tip) 1
44
FeedRollerBracket 1
45
RollerBracketScrew 2
46
RollerBracketWasher 2
47 Washer 1
48
SupportBracket 1
49 Fan 1
50 Lock Washer 1
PLEASE READ THE FOLLOWING CAREFULLY
 THEMANUFACTURERAND/ORDISTRIBUTORHASPROVIDEDTHEPARTSDIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER NOR
DISTRIBUTOR MAKESANY REPRESENTATION OR WARRANTY OFANY KINDTOTHE
BUYERTHATHEORSHEISQUALIFIEDTOMAKEANYREPAIRSTOTHEPRODUCTOR
THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT,
THEMANUFACTURERAND/ORDISTRIBUTOREXPRESSLYSTATESTHATALLREPAIRS
ANDPARTSREPLACEMENTSSHOULDBEUNDERTAKENBYCERTIFIEDANDLICENSED
TECHNICIANSANDNOTBYTHEBUYER.THEBUYERASSUMESALLRISKANDLIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT
PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT
PARTS THERETO.
