Chicco Activ3 User Manual

11
How to Assemble Stroller
Cómo armar el cochecito
2. Line up the holes of the Front
Swivel Mount with the holes on the
Stroller Frame as shown. The Baskets
2 snap buttons can be removed for
better access. Slide the Metal Pin
through the holes on the Stroller
Frame and the Front Swivel Mount.
2. Alinee los orificios en la montura
delantera giratoria con los orificios
en la estructura del cochecito, como
se muestra. El cesta 2 botones de
broche se puede quitar para un mejor
acceso. Deslice la clavija de metal por
los orificios en la estructura y en la
montura.
2

Chicco Activ3 Specifications

General

Type	Jogging Stroller
Weight Capacity	50 lbs
Stroller Weight	27.5 lbs
Fold	One-hand fold
Wheel Type	Air-filled tires
Number of Wheels	3
Seat Recline	Multi-position
Harness	5-point harness
Front Wheel	Swivel
Brakes	Foot-activated
Canopy	Adjustable
Storage	Large storage basket
