2. Attach the Rear Axle Assembly (D)
to the Stroller Frame, as shown. The
Rear Axle Assembly is attached when
the snap buttons click into the holes
on the Rear Axle mount.
“CLICK!”
Snap button
2
3A. On one side of the Rear Axle,
slide a Rear Wheel (C), and turn the
Wheel until the brake tab fits into
one of the grooves on the Wheel.
3A
3B
3B. On the same side, slide a Washer
(E) onto the Rear Axle.
