The Safety Harness can be released by pressing
the button on the center of the Buckle and pulling both
Waist Clips out. Pull up on the Shoulder Strap Connector
to remove it from the Waist Strap Clip.
8
The length of the Shoulder Straps can be
adjusted by pulling on the adjustment buckles to
tighten or loosen. The length of the waist straps can be
adjusted. Press the tab at the end of the Waist Strap
Clip and pull on the strap to tighten or loosen, to better
fit your child.
Refer to the Stroller Owner’s Manual for instructions
on use of the Canopy, Footrest, Armbar, and
Organizer Pocket.
9
1.
2.
3. 4.
The Footrest can be adjusted to 4 positions. Press in on both Footrest
Buttons and, at the same time, rotate the Footrest up or down to the
desired position.
10
To remove Armbar, press in on the buttons located at the sides of the Armbar, as shown. Undo one side of the Armbar,
and swing away to the side. Undo both sides and remove completely. To re-attach the Armbar insert the Armbar Tongues
into the corresponding openings on the Seat Frame.
11
WARNING
Never place more than 1 lb (0.5 kg)
in seat back pocket.
Locate the mesh organizer pocket on the back of the seat.
12
This stroller has a 5-point safety harness. The Shoulder Strap Connector
is designed to break away from the Waist Clip when not secured in the Crotch
Strap Buckle. Make sure the Shoulder Strap Connector is in the correct position, as
shown. Slide the Shoulder Strap Connector onto the Waist Strap Clip and repeat
for the other side. Then slide both Waist Clips into the Crotch Strap Buckle, as
shown. Pull on both sides to make sure the Clips are secured to the Buckle.
7
WARNING
Never leave child unattended. Avoid serious injury from falling or
sliding out. Always use Safety Harness.
