How to Use Lower Modular In/Out Position
The Infant Car Seat can be
installed when the Lower Modular
Attachment is in the OUT
position
34A. Place the Chicco Infant Car
Seat into the Infant Car Seat
Adapter. The Infant Car Seat can
only be attached in a Parent-Facing
position. Make sure Infant Car
Seat clicks into the Infant Car Seat
Adapter on both sides.
Pull up on the Infant Car Seat;
make sure it is secured to Stroller
Frame (34B). If the Infant Car Seat
is not secured see Step 28 to make
sure the Infant Car Seat Adapter is
assembled and attached correctly.
Parent-Facing Infant Seat in
Lower Modular Position OUT
1
CLICK!
CLIC!
CHECK!
!
VERIFICAR!
2
!
34A
34B
The Stroller Seat can be adjusted
to 3 positions when the Lower
Modular Attachment is in the OUT
position
33. To recline the Seat, press the
Recline Button on the back of the
Seat, as shown. Rotate the Seat up
or down to the desired position.
33
1.
2.
3.
How to Use Lower Modular In/Out Position
