Chicco CORSO FLEX - Connect Rear Axle and Lock Platform

8 9
How to Assemble Stroller
4. To lock the Standing Platform
onto the Rear Axle Assembly, flip
the stroller over and turn both
levers, as shown.
The platform levers need to rotate
so that they rest on top of the
Rear Axle and lock the Standing
Platform in place. Pull on the
platform to make sure it is secure
on the axle.
4
How to Assemble Stroller
3
3. Line up the Rear Axle Assembly
(D) to the Stroller Frame. Make
sure the Standing Platform is
in the correct position as
shown in 3A.
Then attach the Rear Axle
Assembly to the Stroller Frame,
making sure both snap buttons
click into the holes on either side
of the Rear Axle mount.
Make sure the Rear Axle bar is
positioned below the Standing
Platform, as shown in 3B.
“CLICK!”
Snap
Button
B.
A.
