BASE INSTALLATION
BASE INSTALLATION
INSTALL USING LAP-SHOULDER BELT INSTALL USING LAP-SHOULDER BELT
Pull any slack out of the lap and shoulder belt.
Make sure the Lap Belt lays flat over the Belt Path on both sides of the
Base Frame (a). Then guide the Shoulder Belt across the back of the
Base Frame and slide it into the Shoulder Belt Path on the opposite side
of the vehicle buckle (b). Make sure the Lap Belt does not slip down in
front of Belt Guide lip (c).
5
5
6
6a
6b
6c
