CHIEF AA Series - Tools Required for Installation

Installation Instructions TIL1X2AA / TIL1X3AA / TIL1X4AA / TILVABAA
4
TOOLS REQUIRED FOR INSTALLATION
PARTS
Hardware Required - not included
(for installation into steel stud walls)
1. Chief brand FCAT1 Toggler Kit; OR
2. Hardware for installation to steel stud wall:
• 1/4-20 Toggler Snaptoggle BB (Qty 4)
• 1/4-20 x 2-1/2" hex head bolt (Qty 4)
• 1/4" washer (Qty 4)
7/32"
#2
Level
[4+ ft. long]
[Small level]
3/8"
1/2"
T-Handle
drive with
1" socket
1/2"
5/32"
(included)
Horizontal Connector Kit
F (4)
5/16 x 2-1/2"
G (4)
UX10x60R
H (2)
[Installation
Connector Kit
K (2)
[Vertical connector]
L (8)
1/4-20 x 1/2"
N (1)
[TIL1X2AA]
P (1)
[TIL1X3AA]
Q (1)
[TIL1X4AA]
TILVABAA Vertical
OR
OR
Mounting Hardware Kit
washer]
J (4)
5/16"
A (2)
[Horizontal
connector]
B (8)
1/4-20 x 1/2"
C (6)
08-32 x 1/2"
D (8)
10-24 x 1-1/2"
E (1)
5/32"
M (1)
5/32"
