Chigo CMV-V160W/ZR1 User Manual

14
GD CHIGO HEATING & VENTILATION EQUIPMENT CO., LTD.
CMV MINI VRF System - Outdoor Unit
1.2 Outdoor unit (14KW, 16KW)
Model name
CMV-V140W/ZR1
CMV-V140W/YR1
CMV-V160W/ZR1
CMV-V160W/YR1
Power supply
380~415V-3ph-50Hz
380~415V-3ph-60Hz
380~415V-3ph-50Hz
380~415V-3ph-60Hz
Max. connected indoor units
Pcs
7
8
Performance data
kW
14
16
Btu/h
47000
54000
RT
4.0
4.5
Power input
kW
3.98
4.58
EER
W/W
3.52
3.5
Heating
Capacity
kW
16
18.5
Btu/h
54000
63000
RT
4.5
5.2
Power input
kW
4.3
5.13
COP
W/W
3.72
3.61
Max. input consumption
kW
6.3
6.3
Max. current
A
10
10
Capacity adjustment range
50%~130%
50%-130%
Compressor data
DC Inverter
compressor
Quantity
1
1
Type
DC /Twin-rotary
DC /Twin-rotary
Brand
Mitsubishi
Mitsubishi
Frequency range
Hz
15~100Hz
15~100Hz
Crankcase heater
W
35
35
Compressor oil
Model
FV50S
FV50S
Original oil volume
ml
200
200
Additional oil volume
ml
1470
1500
Fan data
Fan motor
Type
DC
DC
Brand
Panasonic / Shibaura
Panasonic / Shibaura
Quantity
2
2
Insulation class
E
E
Protection class
IP23
IP23
Power output
W
100*2
100*2
Rated current
A
0.9*2
0.9*2
Fan blade
Material
ASG20
ASG20
Type
Axial
Axial
Drive
Direct-driven
Direct-driven
Fan Quantity
2
2
Air flow
m
3
/h
8000
8000
Vane Quantity
3
3
Physical data
Outdoor coil
Fin type
Hydrophilic Aluminum
Hydrophilic Aluminum
Tube outside diameter
mm
φ7.94
φ9.52
Tube type
Inner-grooved copper tube
Inner-grooved copper tube
Refrigerant
Type
R410a
R410a
Volume
kg
3450
4200
Throttle type
EXV
EXV
