GD CHIGO HEATING & VENTILATION EQUIPMENT CO., LTD.
CMV MINI VRF System - Outdoor Unit
Model name
CMV-V140W/ZR1
CMV-V140W/YR1
CMV-V160W/ZR1
CMV-V160W/YR1
Dimension
(W*H*D)
Net
mm
900×1328×345
900×1328×345
Packing
mm
964x1445x402
964x1445x402
Weight
Net
kg
93
100
Gross
kg
104
111
Outdoor sound level
dB(A)
58
58
Maximum operating pressure
MPa
3.8
3.8
Piping & wiring data
Pipe size
Liquid pipe
mm
φ9.53(flaring nut)
φ9.53(flaring nut)
Gas pipe
mm
φ15.9(flaring nut)
φ15.9(flaring nut)
Max. pipe length
Total pipe length
m
100
100
From OU to farthest IU
m
70
70
From 1st indoor
distributor to farthest IU
m
20
20
Max.vertical
length
Between OU & IU (OU
above IU)
m
30
30
Between OU & IU (OU
below IU)
m
20
20
Between IUs
m
8
8
Connection wire
Power wire size
mm
2
5*2.5
5*2.5
Signal wire type
2-core shielded cable
2-core shielded cable
Signal wire size
mm
2
1
1
Operation temperature range
Cooling
Outdoor side
°C
-5~50
-5~50
Indoor side
°C
16~32
16~32
Heating
Outdoor side
°C
-20~30
-20~30
Indoor side
°C
16~32
16~32
Notes:
1) The cooling conditions: indoor temp.: 27˚C DB (80.6˚F), 19˚C WB (60˚F) outdoor temp.: 35˚C DB (95˚F) equivalent pipe length: 5m
drop length: 0m.
2) The heating conditions: indoor temp.: 20˚C DB (68˚F), 15˚C WB (44.6˚F) outdoor temp.: 7˚C DB (42.8˚F) equivalent pipe length: 5m
drop length: 0m.
3) Sound level: Anechoic chamber conversion value, measured at a point 1 m in front of the unit at a height of 1.5 m. During actual
operation, these values are normally somewhat higher as a result of ambient conditions.
4) Maximum 85Pa outdoor ESP can be set on outdoor PCB.
5) The above data may be changed without notice for future improvement on quality and performance.
