GD CHIGO HEATING & VENTILATION EQUIPMENT CO., LTD.
CMV MINI VRF System - Outdoor Unit
Model
Capacity
A(mm)
B(mm)
C (mm)
D (mm)
CMV-V100W/ZR1
CMV-V100W/YR1
10KW
585
880
360
424
CMV-V125W/ZR1
CMV-V125W/YR1
12.5KW
CMV-V140W/ZR1
CMV-V140W/YR1
14KW
CMV-V160W/ZR1
CMV-V160W/YR1
16KW
2.3 Valve explanation
Thread connection
Braze welding
Braze welding
Gas pipe (accessory)
Liquid pipe (accessory)
