Chigo CMV - Wall-mounted Type Components; Floor and Ceiling Type Components

2. Air conditioner part name and functions
5
2-5 Wall-mounted type
Operation / indicator zone
Refrigerant pipe / electric wire
Power plug
Drain hose
Left / rightwind louver
Up/down wind louver
Air return inlet
Figure 2.5
2-6 Floor and ceiling type
Drain pipe
Air inlet grille
Air inlet
Control panel
Air-outlet
The refrigerant
pipe is connected
to the ground wire
of the power line.
Figure 2.6
