2. Air conditioner part name and functions
3
2-1 4-way Cassette Type
Drainage device (built-in type)
Remove water from
indoor during cooling
Air-outlet
Air filter
(Located in the air return grille)
Wind return gille
Water exhaust pipe
Wind-guide
(Located in the air-outlet)
R
wire
efrigerant pipe
Connecting
Connect the earth wire
Figure 2.1
2-2 High static pressure ducted type
Figure 2.2
Air inlet
Air-outlet
Air-outlet
