19
1
Front Grill
2
Front Plate
3
Axial flow fan
4
MotorT
5
Motor support
6
Left protect net
7
Pillar
8
Condenser
9
Top panel
10
Rear Grill
11
Four-way valve assembly
12
Intake pipe for the condensor
13
Suction pipe
14
Capillary Assy
15
Suction pipe
16
Discharge pipe
17
Electrical boxes
18
Right panel
19
Large handle
20
Valve installation plate
21
High-pressure valve
22
Low-pressure valve
23
Base
24
Compressor
25
Partition board
