Tube pitch* row pitch*Fin
spacing
mm
21*12.7*1.4 21*12.7*1.4
Tube outside dia.and typ mm 7/internal threaded pipe φ7internal threaded pipe
Coil size :length x height
x width
mm
648*462*12.7 605*441*12.7
Outdoor Noise Level dB (High/Low)
(actual/label)
dB(A)
51.1/49 51
Dimension size (L*W*H) mm
700*225*500
680*225*482
Packing size(L*W*H) mm 825*320*550 822*345*535
Net/Gross weight Kg 30/31 25/29
Refrigerant type/weight g R410A/630 R410A/540g
Design pressure (Hi/Low) MPa
3.8/1.2 4.2/1.2
Liquid side/ Gas
side/Length
mm
6.35/ 9.52 /3500
φ6.35＋φ9.52×3500
Refrigerant piping
Max. refrigerant pipe
length
/Max. difference in level
m
15/5 15/5
