Step1 Step2 Step3

Figure 5 Assembly method of NS2-AU

Step1 Step2

Figure 6 Assembly method of NS2-SH/UV

3.2 Wiring

Single core PVC insulated coppoer wire is used, see Table 7 for cross-

sectional area of wires.
