CHINT NVF5-5.5/TS4-B - Technical Specifications

NVF5 Series User Manual Chapter 2 Product Overview
Table 2.1 Inverter Model and Specification
Power
Supply
Catalog No.
Power
Capacity
kVA
Input
Current
A
Output
Curren
t
A
Adaptiv
e Motor
kW
Brak
e
Unit
Single-Phase
AC 230V
NVF5-0.4/TD2
1.0 5.4 2.5 0.4
Optio
nal(e
mbed
ded)
NVF5-0.4/TD2-B
NVF5-0.75/TD2
1.9 10.3 5 0.75
NVF5-0.75/TD2-B
NVF5-1.5/TD2
2.9 15.5 7.5 1.5
NVF5-1.5/TD2-B
NVF5-2.2/TD2
4.2 20 10 2.2
NVF5-2.2/TD2-B
Three-Phase
AC
380V~440V
NVF5-0.4/TS4-B 0.8 2.3 1.5 0.4
Stan
dard(
embe
dded)
NVF5-0.75/TS4-B 1.5 3.4 2.7 0.75
NVF5-1.5/TS4-B 3.0 5.1 4.2 1.5
NVF5-2.2/TS4-B 4.0 6.6 5.8 2.2
NVF5-3.7/TS4-B 5.9 12.1 10.5 3.7
NVF5-5.5/TS4-B 8.6 13.1 13 5.5
NVF5-7.5/TS4-B 11.0 22.2 17 7.5
2.4 Technical Specifications
Form2.2 Specifications
Item
Description
Input
Voltage range
Three-phase 380~440V
：
380 V
（
-15%
）
~440 V
（
+15%
）
Single-phase 230V
：
230 V
（
±15%
）
Frequency range
（
47
～
63
）
Hz
Output
Voltage
0
～
rated input voltage
Frequency
（
0
～
400
）
Hz
Overload capacity
150
％
of rated current for up to 1 minute,and 180
％
of
rated current for up to 2 seconds
Main control
function
Control mode
SVC control
、
V/F control
、
Torque control
Start torque
SVC
：
150% rated torque at 0.5Hz
V/F
：
100% rated torque at 1Hz
Carrier frequency
1kHz~15kHz
