NVF5 Series User Manual Appendix B Parameter list
Code
Name
Setting Range
Default
Change
F5.39
Curve 4 Break Point 1
Reference
F5.37 ～ F5.41
3.00V
○
F5.40
Curve 4 Break Point 1
Setting
（-100.0 ~ +100.0）%
30.0%
○
F5.41
Curve 4 Break Point 2
Reference
F5.39 ～ F5.43
6.00V
○
F5.42
Curve 4 Break Point 2
Setting
（-100.0 ~ +100.0）%
60.0%
○
F5.43
Curve 4 Max.
Reference
F5.41 ～ +11.00V
10.00V
○
F5.44
Curve 4 Max.
Reference Setting
（-100.0 ~ +100.0）%
100.0%
○
F5.45
AI/HDI
Lower Limit
Selection
0x0000 ~ 0x0111
0：Limit to Min. Reference Setting
1：Limit to 0.0%
Ones Place：
AI1
Lower Limit
Selection
Tens Place ： AI2
Lower Limit
Selection
Hundreds Place ： HDI Lower
Limit Selection
Thousands Place：Reserve
0x0000
○
F6 Digital Output Terminal Group
F6.00 HDO Output Type
0：
Collector Open-
Circuit High
Speed Pulse Output
1：Collector Open-Circuit Output
（F6.01 Setting）
0
○
F6.01 HDO Output Selection
0 ～ 63
0：No Output
1：In Running Mode
2 ：
Frequency Level Detection
Reach-FDT1
3 ：
Frequency Level Detection
Reach -FDT2
4：Inverter Overload Pre-Alarm
5：Under Voltage Status Output
6：External Fault Stop
7：
Reach Upper Limit Frequency
8：Reach Lower Limit Frequency
9：Zero Speed Running
10~11：Reserve
12：Simple PLC Step Complete
Indication
13：PLC Recycle Complete
14：Reserve
1
○
F6.02
Relay Output
Selection
16
○
F6.03 Reserve --
○
- 122 -
