Specifications
Input: Coax, optical and USB digital inputs with input switch
Output: 3v RMS 1kHz RCA phono
Sample Rate: 32-bit/384kHz via coax and USB, and 24-bit/192kHz via optical
USB specification: 32/384kHz galvanically isolated class compliant
Dynamic range: -119dB A/Wt
THD: 0.0003% at 3v RMS 1kHz; 0.0002% at 2v RMS 1kHz
Crosstalk: 126dB 1kHz
Frequency Response: +/- 0.1dB 20-20kHz
Power supply: 12V 0.5A
Dimensions: 0.4Kg
Weight: 160x70x40mm (width x height x depth)
