Model 108 Two Motor Tandem Installation Instruction
4
SAFETY INFORMATION
Use caution when working with the
Auger--springing auger may cause personal injury.
CAUTION
Model 108 Two Motor Tandem Systems
PLAN CAREFULLY BEFORE BEGINNING TO INSTALL THE MODEL 108 TWO-MOTOR
TANDEM SYSTEM. PLACEMENT OF BINS IS IMPORTANT FOR PROPER INSTALLATION OF
THE TWO-MOTOR TANDEM SYSTEM.
Pour one level concrete pad for BOTH bins. Pad dimensions and specifications must meet bin
manufacturer’s requirements. Position the bins so that legs will not interfere with the Flex-Auger
system installation.
Two-Motor Model 108 Tandem systems may have more than two bins connected together, but
additional components are required.
Bin Location
Locate the bins as illustrated in Figure 1. Note that bins may be installed in-line or forming a 90
degree angle with the system.
Boot Installation
Upper boot installation is the same for both the terminal and intermediate bins. Both bins require
Straight-Out Boots with the Two-Motor Tandem System. Install the boots as described in this
manual.
Using this equipment for any other purpose or in a way not within the
operating recommendations specified in this manual will void the
warranty and may cause personal injury and/or death.
This manual is designed to provide installation, wiring, and parts
listing information.
IMPORTANT: CE stands for certified Europe. It is a standard which
equipment must meet or exceed in order to be sold in Europe. CE
provides a benchmark for safety and manufacturing issues. CE is
required only on equipment sold in Europe.
Chore-Time Equipment recognizes CE Mark and pursues compliance
in all applicable products.
Refer to Chore-Time Model 108 Installation Manual for additional
installation, operation, and parts listing information.
