Chris King Classic - Hub Specifications and Wheel Building Information

16
Hub specifications and
wheel building information
Hub Type Axle Type
Axle Width
(mm)
Flange
Diameter
Drive Side
(mm)
Flange
Diameter
non-Drive
Side (mm)
R45 front two piece 100 39.8 39.8
R45 rear one piece 130 51.0 51.0
R45 Campagnolo rear one piece 130 51.0 51.0
R45 ceramic front two piece 100 39.8 39.8
R45 ceramic rear one piece 130 51.0 51.0
R45 Campagnolo ceramic rear one piece 130 51.0 51.0
Classic Road / Cross / Mtn front two piece 100 53.0 53.0
Classic Road / Cross rear two piece 130 53.0 53.0
Classic Mountain rear one piece 135 53.0 53.0
Classic low flange front two piece 100 40.0 40.0
Classic low flange rear two piece 130 53.0 44.0
Classic Mtn low flange rear two piece 135 53.0 44.0
Single Speed Road rear one piece 130 53.0 53.0
Single Speed Mountain rear one piece 135 53.0 53.0
BMX high flange front one piece 100 53.0 53.0
BMX high flange rear one piece 110 53.0 53.0
BMX low flange front one piece 100 40.0 40.0
Frame Attachment Options
QR: Quick release only
BO: Bolt-on only
QR / F B: Quick release or FunBolts (FunBolts only compatible with rear one piece axle)
Wheel Building Specifications
Spoke Gauge: 13, 14, or 15 gauge
Spoke Lacing Pattern: All hubs 3-or-more cross, except R45 Hubs are 1-or-more cross
Spoke Hole Diameter: 2.5mm
Center to
Flange Drive
Side (mm)
Center to
Flange non-
Drive Side
(mm)
Frame
Attachment
Options
Available
Spoke Hole
Drilling
Upgrade &
Conversion
Options
Weight*
(grams)
34.8 34.8 QR 20, 24, 28, 32 - 103
18.9 34.6 QR 24, 28, 32 - 221
17.1 36.2 QR 24, 28, 32 - 225.7
e
34.8 34.8 QR 20, 24, 28, 32 - 99
18.9 34.6 QR 24, 28, 32 - 216
17.1 36.2 QR 24, 28, 32 - 216.5
e
34.3 34.3 QR 28, 32, 36 - 136
17.2 3 7. 3 QR 28, 32, 36 1, 2, 3 276
21.0 33.5 QR/FB 28, 32, 36 1, 2, 3 302
34.0 34.0 QR 28, 32, 36 - 112
18.5 38.5 QR 28, 32, 36 1, 2, 3 264
21.0 36.0 QR 28, 32, 36 1, 2, 3 266
31.2 36.2 QR/FB 28, 32, 36 1 370
a
33.7 33.7 QR/FB 28, 32, 36 1 375
a
34.3 34.3 BO 28, 32, 36 - 216
b
2 7. 3 2 7. 3 BO 28, 32, 36 - 388
c
34.0 34.0 BO 28, 32, 36 - 194
b
Upgrade & Conversion Options
1. Convertible to 130mm and 135mm one piece axle (allowing FunBolts option)
2. Convertible to 130mm, 135mm, and 140mm axle widths when using a two piece axle
3. Convertible to stainless steel driveshell
Weight Details
* Add 48g if hub features a stainless steel driveshell
a. Weight includes 18t stainless steel cog (37g), Single Speed cog spacers (6g) Single Speed iiiiii iii
cog lock ring (4g) and FunBolts (42g)
b. Weight includes BMX axle bolts with washers (44g/pair)
c. Weight includes BMX axle bolts with washers (44g/pair), 16t stainless steel cog (32g), iiiiiillii
and Single Speed cog lock ring (4g)
d. Weight includes FunBolts (42g)
e. Campagnolo hubs come with an 11-tooth lock ring (5.5g).
Optional 12-tooth lock ring available aftermarket.
